OUR PARTITIONS SYSTEMS
AUTOMATIC
Skywall
The Skywall is a vertical acoustic wall partition that automatically unfolds downwards from the ceiling. The electro-mechanical contraction of the modules is swift and effortless via electronic controls, provided with safety astragals. The Skywall view features translucent window panes with Sound Transmission Class STC-51 and STC-52. The Skywall-solid can be installed in rooms with high ceilings, offering acoustic isolation of up to STC-59
Continuously Hinged Panel
The Continuously Hinged Panel is an automatic electric acoustic wall solution that deploys in a straight line along the opening via electric controls.
MANUAL & SEMIAUTOMATIC
Single Panel
Single Panel acoustic wall partitions are independent modules hanging from a top rail. The Series X1 panels are 3.15 inches thick with isolation up to STC-53, while our Series X2 panels are 4 inches thick with STC-58. The frames are constructed with continuous pieces of rolled steel frames up to 60 feet tall, composed faces in a structurally robust and durable configuration. Vertical sound seals are made of 16 gauge steel in a tongue and groove arrangement to ensure panel-to-panel alignments, and two collapsible tubular vinyl gasket seals guarantee an airtight joint between panels. Pass doors within the panels with drop-down and perimeter seals can be accommodated as required within dividing walls.
Paired Panels
Paired Panels acoustic wall partitions have the same topology as Single Panel partitions but are built to hang in hinged pairs that move in a straight line, allowing for greater ease and efficiency in space transformation.
